Technical Data Sheet – Tero Vido X-Series

Probes

Sensors – 4x 3-axis magnetic field sensors

Built-in battery – Type Li-ion Battery

Performance data – 3500 mAh

Internal operating voltage – 3.7 V

Battery life: 12 h

Charging time: 4 h

Chargers – 5V/2 A

Input voltage 5 V-USB Charger

Charging current 2 A

IP protection class IP 44

Storage temperature -10°C – 55°C

Operating temperature -10°C – 45°C

Relative humidity 90 % (non-condensing)

Radio module for data-transfer

Frequency 2.45 GHz

Operating channels 13

Transmission rate (air) up to 7 mbits/s

Max. output +20 dBm

Sensitivity -98 dBm

Processor

Micro controller 8 Bit RISC

Max. operating frequency 16 MHz

Certificates

• Conformity with CE directives
• FCC certified; WEEE-Reg.-Nr.: DE 73865556
• FCC 2AHMR-ESP12S
• ICC Certificate of Origin

Made in Germany

Computer requirements

• Operating system Windows 10, Android, IOS
• Drive CD-ROM drive; alternatively the software can be downloaded from the company website
• USB No
• Bluetooth No
• Processor speed Min. 1,5 GHz
• Memory 1 GB RAM
• Disk space 500 MB
• Graphic card OpenGL required

The following table shows the complete scope of delivery and all optional accessories. The symbols used have the following meaning:

Technical certificates and 2 years warranty are standard for all Tero Vido 3D System ground scan devices. Before the goods are leaving our company, they are thoroughly tested by our engineers. That, and intense field tests and constant improvements make sure that we deliver continuously high quality and provide you always one of the professionals available on the market.
