3D System

The Tero Vido 3D System is a 3D measuring device for the detection and precise localisation of anomalies in the ground. It is based on newly developed and measuring technology from Tero Vido UG, Germany. The whole device has been developed and manufactured in Germany. This detector helps you to discover and discriminate all kinds of metal. The included software shows if you found magnetic metals like iron or steel, or non-magnetic precious metals such as gold, silver or copper.  Furthermore, the Tero Vido System is best suited to detect and locate underground voids, such as bunkers, graves, tunnels or other rooms.

One thing that makes the Tero Vido System quite special, besides the exact localisation, is the deep penetration of the ground. Depending on the size of the object, significant depths of up to 18m can be reached. The multi-language user interface of the proprietary software is currently available in English, German, French, Russian, Arabic, Turkish, Spanish, Greek, Romanian and Bulgarian. More languages are coming soon.The automatic and free software updates contain, besides software improvements also further new languages.

The Tero Vido 3D System is built extremely simple and can be used by anyone after only a short training period. It consists of the inconspicuous and lightweight ground scanner and a portable computer (tablet). No cables or heavy batteries impede the work with the machine.

The user scans the ground with the sensor, and the scan results are shown in real-time on the computer screen. Immediately after finalising the measuring process the results can be analysed in the software. The data will be stored on the computer and can be retrieved when necessary. The storage capacity, as well as the size of the measuring field is nearly unlimited.

The high resolution graphic, one of the best and most detailed resolutions on the market, along with the many options for adjustment in the software facilitate the quick detection of the metal or void, and determine its depth and size. The system delivers repeatable results and a control scan will confirm the measuring result. You can also use the Tero Vido 3D System for metal discrimination and see, if your find is made of ferromagnetic metals or non-ferromagnetic precious metals. The Tero Vido 3D Systems is an all-purpose device and can be used on any ground condition be it sandy, rocky or loamy. Small metal anomalies in highly mineralized grounds can be filtered with the software.

  • Tablet with pre-installed software Tero Vido 3D
  • Sensor ………………… Vertical, 85 cm
  • USB-Dongle for data exchange between sensor and computer
  • Charging cable and adapter for USB ………………… 12 V DC and 220 V AC
  • Manual and Quick Start Guide
  • Flexible tablet carrying case with touch-sensitive screen protection
  • Transport bag for sensor
  • Headphones (Bluetooth/WiFi)
  • Tablet with pre-installed software Tero Vido 3D
  • Sensor ………………………… Vertical 85 cm
  • Sensor 2 ………………………… Horizontal, 50 cm
  • Carrying rod for horizontal sensor
  • USB-Dongle for data exchange between sensor and computer
  • Charging cable and adapter for USB …………………… 12 V DC and 220 V AC
  • Manual and Quick Start Guide
  • Flexible tablet carrying case with touch-sensitive screen protection
  • Solid transport box for sensors and tablet, Peli case - waterproof
  • Headphones (Bluetooth/WiFi)
  • Tablet with pre-installed software Tero Vido 3D
  • Sensor 1 ……………………………… Vertical, 85 cm
  • Sensor 2 …………………………. Horizontal, 50 cm
  • Sensor 3 ………………………… Horizontal, 100 cm
  • Carrying rod for horizontal sensor
  • Temperature measuring device for voids
  • USB-Dongle for data exchange between sensor and computer
  • Manual and Quick Start Guide
  • Flexible tablet carrying case with touch-sensitive screen protection
  • Solid transport box for sensors and tablet, Peli case - waterproof
  • Headphones (Bluetooth/WiFi)
Download the technical data sheet (PDF, 0,6 MB)

    Probes

  • Sensors ……………………………… 3-­‐axis digital sensors
  • Built-­‐in rechargeable battery

    • Type ……………………………… LiPo rechargeable battery
    • Performance ……………………………… parameters 800 mAh 4,2V
    • Internal ……………………………… operating voltage 3,0V
    • Battery ……………………………… run-­‐time 15h
    • Charging ……………………………… time 1h with mains adapter, 4h with in-­‐car charger

    Charger

    • Input voltage ……………………………… 240/110 V or 12 V (in-­‐carcharger)
    • Charging current ……………………………… 5 V/ 500 mA max.

    Measurement and weight of probes

    Designation
    • Length
    • Diameter
    • Weight
    Horizontal probe 100
    • 100cm
    • 5cm
    • 1,2kg
    Horizontal probe 50
    • 50cm
    • 5cm
    • 0,5kg
    IVertical probe
    • 85cm
    • 5cm
    • 0,8kg
    • IP protection category ……………………………… IP 54 (splash-­‐proof)
    • Storage temperature ……………………………… -20° to + 60°C
    • Working temperature ……………………………… -10° to + 50°C
    • Relative humidity ……………………………… 5-95%, non-condensing
    • Notifications ……………………………… Multi-colour LED

    USB radio module for data tranfer

    • Frequency band ……………………………… 2.4GHz ISM band
    • Channels ……………………………… 126 RF channels
    • Transmission rate (air) ……………………………… 2Mbps
    • Programmable output ……………………………… 0. -6, -12 or -18 dBm
    • Sensitivity ……………………………… -82 dBm Sensitivity at 2 Mbps

    Processor

    • Microcontroller ……………………………… 8-bit RISC-based Microcontroller
    • Maximum working frequency ……………………………… 16MHz
    • 1KB SRAM, 512K EEPROM
    • 10-bit A/D converter

    Data tranfer (Bluetooth)

    • Frequency range ……………………………… 2,5 - 2,4835 GHz
    • Maximum transfer rate ……………………………… 1 Mbps
    • Receiver sensitivity ……………………………… -85 dBm
    • Maximum reach in the open ……………………………… Approx. 10 m

    Technical requirements for computer

    • Operating system ……………………………… Windows 8.1. or newer
    • Disk drive ……………………………… CD-­‐ROM drive; alternatively: software download from company website
    • USB ……………………………… USB 2.0 or higher
    • Bluetooth ……………………………… For the Headphones
    • Processor speed ……………………………… 1 GHz
    • Working memory ……………………………… 1 GB RAM
    • Disk space ……………………………… HDD 250 MB
    • Graphic card ……………………………… DirectX9 compatible

Technical certificates and 2 years warranty are standard for all Tero Vido 3D System ground scan devices. Before the goods are leaving our company, they are thoroughly tested by our engineers. That, and intense field tests and constant improvements make sure that we deliver continuously high quality and provide you always one of the professionals available on the market.

We deliver tax free to private and business clients in countries outside the EU. Ask for options and quotes! We will help you to find the best detector for your needs!

Certificates

  • Conformity with CE-guidelines
  • FCC certified; WEEE-Reg.-Nr.: DE 73865556
  • ICC Certificate of Origin
  • Made in Germany
